Descrição
Since 1917 Tsubakimoto Chain Company has maintained a line-up of cutting-edge chain products with exceptional quality and performance that help end-users meet their power transmission and conveying requirements.
Tsubaki is proud to introduce the 4th generation, enhanced BS/DIN European premium chain. The product is available in chain sizes from RF06B up to RS48B*. Simplex, duplex and triplex executions are at your disposal.
*RF06B curled bush; RS56B/RS72B on request
Características
| SIMPLES |
|
|
| Corrente Tsubaki No. | Passo | Diâmetro do Rolo | Lar. Int. do Elo Interno | Pinos | Placas | Força de tensão máxima |
Peso Aproximada |
|||||
| P | d1 | b1 | Diâmetro (D2) | Dimensões (L1) |
(L2) | Comprimento (L) |
Espessura (T) | Altura H(max.) | kN | Kg/m | ||
| RS40-AS-1 | 12.70 | 1/2" | 7.92 | 7.95 | 3.97 | 8.25 | 9.95 | 18.60 | 1.50 | 12.00 | 0.69 | 0.64 |
| RS50-AS-1 | 15.875 | 5/8" | 10.16 | 9.53 | 5.09 | 10.30 | 12.00 | 23.90 | 2.00 | 15.00 | 1.03 | 1.04 |
| RS60-AS-1 | 19.05 | 3/4" | 11.91 | 12.70 | 5.96 | 12.85 | 14.75 | 29.40 | 2.40 | 18.10 | 1.57 | 1.53 |
| RS80-AS-1 | 25.40 | 1" | 15.88 | 15.88 | 7.94 | 16.25 | 19.25 | 39.00 | 3.20 | 24.10 | 2.65 | 2.66 |
